Single Acting Pneumatic Actuator with Travel Adjustment ±5º High Performance Springs and Precision Ground Pinion
Productdetails:
Betalen & Verzenden Algemene voorwaarden:
| Min. bestelaantal: | 1 |
|---|
|
Gedetailleerde informatie |
|||
| Model nr.: | VS-052 ~ vs-400 | Stroom: | Pneumatisch |
|---|---|---|---|
| Drukrichting: | Dubbelwerkende cilinder | Pignonmateriaal: | Verhard Legeringsstaal |
| Rondsel coating: | Vernikkeld (meer dan 15um) | Materiaal behuizing van actuator: | Aluminium extrusie |
| Coating van behuizing van actuator: | Hard geanodiseerd (meer dan 30um) | Het materiaal van Beëindigenglb: | Die casting aluminium |
| Eindkapcoating: | Epoxycoating (meer dan 80um) | Zuiger materiaal: | Die casting aluminium |
| Zuigercoating: | Hard geanodiseerd (meer dan 30um) | Reisaanpassing: | ±5º in open/gesloten posities |
| Lentemateriaal: | Staal met grote trekspanning | Lente coating: | Met een laag bedekt epoxy |
| Lagers materiaal: | Zeer duurzame samenstelling | ||
| Markeren: | Travel Adjustment ±5º Pneumatic Actuator,High Performance Springs Pneumatic Air Actuator,Precision Ground Pinion Pneumatic Rotary Actuator |
||
Productomschrijving
Single Acting Pneumatic Actuator
Key Features
- Position Indicator: Standard Namur mounting for accessory attachment on all VESON pneumatic actuators
- Precision Pinion: Hardened alloy steel with nickel plating (over 15μm) for reduced friction and maximum wear resistance. Complies with ISO5211 & DIN3337 standards. Custom dimensions and material options (stainless steel, aluminum alloy) available
- Durable Actuator Body: Hard-anodized aluminum extrusion (over 30μm) for corrosion protection and minimal piston friction. Optional epoxy or PTFE coatings available
- Corrosion-Resistant End Caps: Epoxy-coated (over 80μm) die-cast aluminum with optional PTFE treatment
- Precision Piston: Hard-anodized (over 30μm) die-cast aluminum with high-quality guides. Twin rack and pinion design ensures consistent torque output
- Adjustable Travel: ±5° adjustment in both open and closed positions via external adjustment bolts
- High-Performance Springs: Epoxy-coated high tensile steel for corrosion resistance and extended service life. Pre-loaded design allows safe, rapid disassembly
- Premium Bearings & Guides: High-durability compound material provides stable thrust with minimal friction for long operational life
Product Images
